Description
Hydraulic Liner Hanger Pocket Slip Non-Rotating Liner Hanger Shell TPCQ Connection
The Liner Hanger is made of high-quality alloy steel, with high mechanical strength and a large weight.the Liner Hanger Suitable for vertical wells, shallow wells, and wells with relatively stable wellbore walls.
The Liner Hanger achieves tail pipe suspension through hydraulic transmission and is widely used in oil wells, natural gas wells, brine wells,geothermal wells as well as technical and production casing cementing for coalbed methane.
Liner Hanger divided into hydraulic Liner Hanger,Rotating Liner Hanger,Mechanical Liner Hanger,Packer Liner Hanger,Expansion Liner hanger,Non-Rotating Liner Hanger.
hydraulic Liner Hanger and mechanical Liner Hanger suspensors mainly consist of Hydraulic Set Liner Hanger suspension assemblies,feeding tool assemblies,sealing assemblies,ball seat assemblies,rubber plugs,float clamps,float shoes,center pipe couplings etc.
Characteristics of Mechanical Liner Hanger
1. Implement sitting and hanging through lifting, lowering, rotating, and other methods
2. Hydraulic seat suspension with high success rate
3. Multiple choices can be applied to packer Liner Hanger cementing of different weights:
4. Suitable for vertical wells, shallow wells, and wells with relatively stable wellbore walls.
5. No need to throw the ball to suppress pressure, not limited by pump pressure, simple operation.
